Wayne SPF33 Manuel D'installation

Sump, Effl uent and Sewage pumps
INSTALLATION MANUAL
Read and save these instructions. This manual contains very important Safety Warnings and Operating Instructions. You will need to refer to
it before attempting any installation or maintenance. Always keep this manual with the unit so that it will be easily accessible. Failure to read
and follow these warnings and instructions could result in property damage, serious injury or death.
DESCRIPTIONS
SUMP PUMPS
Sump pumps are automatic pumps used to remove ground
water from sump pits. The most common application is for
basement drainage to prevent fl ooding in residential buildings.
These sumps are designed to pump clear water only.
EFFLUENT PUMPS
Effl uent pumps are pumps used to remove grey water from
septic tanks, sump pits or laundry tray systems. Grey water
is waste water from bathtubs, sinks, washing machines, and
other kitchen appliances. The pumps are designed to pass
solids 1/2 to 3/4 inches in diameter.
SEWAGE PUMPS
Sewage pumps are pumps used to remove waste water
that contains solids up to 2 inches in diameter. The most
common application is for draining bathroom waste water to
a sewer or septic line.
IMPORTANT SAFETY INFORMATION
WARNING INDICATES A POTENTIALLY HAZARDOUS
SITUATION WHICH, IF NOT AVOIDED, COULD RESULT
IN DEATH OR SERIOUS INJURY.
RISK OF ELECTRIC SHOCK. TO REDUCE THIS
RISK, OBSERVE THE FOLLOWING WARNINGS:
MAKE SURE THERE IS A PROPERLY GROUNDED
RECEPTACLE AVAILABLE.
grounding conductor and grounding-type attachment plug. To
reduce the risk of electric shock, be certain that it is connected
only to a properly grounded, grounding-type receptacle.
NEVER REMOVE THE GROUND PRONG from the plug or
bypass the grounding wires.
FOR ADDED SAFETY the receptacle should be protected with a
ground fault circuit interrupter (GFCI). All wiring must be performed
by a qualifi ed licensed electrician and comply with the National
Electric Code and all applicable local codes and ordinances.
DO NOT REMOVE POWER SUPPLY CORD and strain relief or
connect conduit directly to the pump.
MAKE SURE THE POWER SUPPLY HAS A FUSE OR
CIRCUIT BREAKER rated to handle the current (amps) noted
on the pump nameplate or cordtag.
© 2011
This pump is supplied with a
Printed on 100% Recycled Paper
UNPACKING
Inspect your pump. Occasionally, products are damaged during
shipment. If the unit is damaged, contact our Customer Service
department at the number listed on the parts and warranty sheet.
READ & FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS — DO NOT DISCARD
SAFETY GUIDELINES
This manual contains information that is very important
to know and understand. This information is provided
for SAFETY and to PREVENT EQUIPMENT PROBLEMS.
To help recognize this information, observe all safety
information labeled danger, warning, caution, and notice.
DO NOT USE AN EXTENSION CORD. Extension cords could
present a safety hazard if not sized properly, become damaged
or the connection falls into the sump. If receptacle is not within
reach of the pump's power cord, contact a qualifi ed licensed
electrician to install a new receptacle.
ALWAYS DISCONNECT THE PUMP from power supply before
installing, servicing or making any adjustments.
DO NOT SUBMERGE PEDESTAL MOTOR or allow motor to
be exposed to water.
DO NOT WALK on the fl oor when water is present until all
power is turned off. If the electric panel is in the basement, call
an electrician.
NEVER HANDLE A PUMP or motor with wet hands or when
standing on a wet or damp fl oor while the pump is plugged into
the power supply.
WASH HANDS AFTER HANDLING. According to the state of
California (Prop 65), this product may contain chemicals known to
the state of California to cause cancer and birth defects or other
reproductive harm.
RISK OF ELECTRIC SHOCK.
investigated for use in swimming pool and marine areas.
DO NOT USE TO PUMP FLAMMABLE OR EXPLOSIVE FLUIDS
such as gasoline, fuel oil, kerosene, etc. Do not use in a fl ammable
and/or explosive atmosphere. Pump should only be used to pump
clear water. Personal injury and/or property damage could result.
PUMPS ARE NOT DESIGNED TO TRANSFER WATER
INTENDED FOR DRINKING. Do not use the pump for moving
water that will be used for potable/drinking water. Pump
should only be used in applications for which it is designed.
This pump has not been
