AXIS M32 Series

Install the hardware

IMPORTANT! -
The casing of AXIS M3203-V and AXIS M3204-V is not
approved for outdoor use - the product may only be installed in indoor
environments.
Mount the camera
The AXIS M32 Series network cameras can be mounted with the cables
routed through the wall/ceiling, or from above or below. There are cover
plates for the openings on both sides of the dome cover.
The AXIS M32 Series can also be fitted with a metal conduit for
protecting the cabling when connected via the side openings. See the
illustrations on page 8.
1. Using the drill template, drill two holes in the ceiling/wall. Ensure
the camera is positioned so that the tamper-proof screws can be
tightened using the supplied screwdriver.
2. Route the required cables.
3. Fasten the camera unit to the ceiling or wall, using screws and plugs
appropriate for the ceiling/wall material.
4. Proceed to Access the video stream, on page 10.
Page 9
