These instructions describe the installation and the setting
options on the 60906 decoder. Unless otherwise indicated,
the functions refer to this decoder.

Intended Use

The 60906 decoder is for upgrading Märklin locomotives
with drum-style or flat commutator field coil motors, i.e. the
motor may not have permanent magnets installed for the
field magnet.
This decoder is installed as a replacement for the mecha-
nical reverse unit, the C80 decoder (6080), or the Delta
decoder.
Contents as Delivered
decoder with wires
mounting plate
countersunk screw
Installation instructions
Warranty card
Tools required for the installation: Screwdriver, tweezers, and
soldering station for a soldering temperature up to maximum
of 30 watts / 400˚C / 752˚F with a thin point, electronics solder
(0.5-1 mm dia.), unsoldering wick or unsoldering vacuum
pump.
12

Safety Notes

• IMPORTANT! Sharp edges due to function design.
• Not for children under 15 years.
• Wiring and assembly work to be done only in the absence
of voltage. Lack of adherence to this can lead to dan-
gerous body current and thereby to injury.
• Operate decoder only with the permissible voltage (see

technical data).

There is the danger of skin burns when working with
the soldering iron.
Technical Data
• Dimensions (L x W)
• Continuous load at motor outputs
• Load at light outputs
• Load AUX 1 – AUX 2 ea.
• Load AUX + light(s) (total)
• Max. load (total)
• Max. voltage
• Short circuit and overload protection at the outputs Front
Light(s) (LV), Rear Light(s) (LH), AUX 1 – AUX 2 and at the
motor outputs.
35 x 20.4 mm / 1-3/8" x 13/16"
≤ 1.6 amps
≤ 1.4 amps
≤ 1.4 amps
≤ 1.4 amps
≤ 1.6 amps
≤ 40 volts
