COMMON FEATURES FOR ALL MODELS

Interior light

Your unit is equipped with progressive lighting that will progress from off to bright when the door is
opened and darken from bright to OFF when the door is closed.
If you prefer to have the light ON at all times, simply press and hold the light ON/OFF button for
approximately 3 seconds to activate the ON mode.
The lights will remain on even if the door is opened and closed.
If you want to return to the progressive mode, simply press and hold the light ON/OFF button again
for approximately 3 seconds and the unit will return to progressive mode.
Your unit is equipped with a selectable color lighting system which will allow you to select the
interior lighting color from the standard White to Cool Blue to Warm Amber.
To change the interior lighting color simply press and release the light ON/Off button. The light
color will change from White then to Cool Blue then to Warm Amber.

Door Ajar Alarm

Your unit is equipped with an audible alarm to alert you when the door has been left open.
If at any time the door has been left open for more than 5 minutes at a time, the alarm will sound
and then will continue to sound until the door is closed completely or the unit is powered off.

HIGH Temperature Alarm

Your unit is equipped with an additional warning system that will alert you if the inside temperature
of the unit raises above 72º F / 22º C.
Once the unit has been connected and running for over 10 hours, if the inside temperature of the
unit raises above 72ºF / 22ºC, the display will flash continuously the word "HI", if the temperature
does not lower and the display flashes "HI" for over 10 hours, then compressor will stop
automatically. This indicates there is an issue with the unit and you should turn it off and find the
cause of the temperature issue.
Storage
Many bottles may differ in size and dimensions. As such the actual number of bottles you may be
able to store may vary.
Shelves (Applies to WCSE47R3S / WCDE46R3S – ONLY)
This appliance is equipped with a pull-out roller assembly and you can move the wooden shelves
out and in smoothly.
To prevent damaging the door gasket, make sure to have the door all the way opened when pulling
shelves out of the rail compartment. For easy access to the bottles, you can pull the shelves out to
their full extension.
To remove the shelves out of the rail pull each shelf out to full extension. Use a long flat
screwdriver to press down the right plastic notch as shown in Figure A and at the same time lift the
left plastic notch as shown in Figure B. Then proceed to pull out the shelf slowly.
Figure A
Figure B
15
