Operating Instructions & Parts Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and
others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for
future reference.
Dyna-Glo
Gas Construction Heater
Description
Dyna-Glo Delux model RMC-FA150NGDGD is a natural gas fired construction
heater, having a built-in thermostat, and a 150,000 BTU/Hr rating. The heater
uses natural gas for com bustion and electricity to operate the motor and fan.
It is primarily to be used to temporarily heat well-ventilated buildings under
construction, alteration or repair. This heater should be utilized in sheltered, well-
ventilated areas, but never in occupied dwellings.
Specifications
Output Rating
Model BTU/Hr
RMC-FA150NGDGD 150,000
Manifold
Model Pressure
RMC-FA150NGDGD 4" W.C.
Model Ignition
RMC-FA150NGDGD Continuous spark
Table of Contents
Description . . . . . . . . . . . . . . . . . . . . . . .1
Specifications. . . . . . . . . . . . . . . . . . . . . .1
Unpacking . . . . . . . . . . . . . . . . . . . . . . . 1
General Safety Information . . . . . . . . 1-3
Principals of Operation. . . . . . . . . . . . . .3
Ventilation. . . . . . . . . . . . . . . . . . . . . . . .3
Installation. . . . . . . . . . . . . . . . . . . . . . . .4
Operation . . . . . . . . . . . . . . . . . . . . . . . .4
Maintenance . . . . . . . . . . . . . . . . . . . . 4-5
Storage . . . . . . . . . . . . . . . . . . . . . . . . . .5
Wiring Diagram. . . . . . . . . . . . . . . . . . . .6
Repair Parts Illustration . . . . . . . . . . . . .7
Repair Parts List. . . . . . . . . . . . . . . . . . . .7
Troubleshooting Chart . . . . . . . . . . . . . .8
Warranty . . . . . . . . . . . . . . . . . . . . . . . . .9
Unpacking
1. Unpack all materials used to protect
the heater inside of carton. Retain
plastic caps attached to exposed
Delux Natural
®
US
ANS Z83.7-2011 CSA 2.14-2011 Construction Heater
Fuel
Fuel Consumption
Natural Gas Only 146 Cubic ft/h
(4.13 m /h)
3
Maximum Supply Minimum Supply
Pressure to Heater Pressure to Heater
1/2 PSI 5" W.C.
Spark Plug
Gap (Inches)
.12
(3.05 mm)
Page fittings for use during storage.
2. Remove heater, accessories and all
hardware from carton.
3. Inspect all items for damage that may
have occurred during shipment.
General Safety Information
Make certain you read and understand
all warnings. Keep these instructions for
reference. They are your guide to safe
and proper operation of this heater.
Safety information appears throughout
these instructions. Pay close attention
to them. Below are definitions for the
safety information listed throughout
this manual.
Indicates an
DANGER
im minen tly
hazardous situation which, if not
avoided, WILL result in death or serious
injury.
Indicates a poten­
WARNING
Printed in China
Figure 1 - Model RMC-FA150NGDGD
Hot Air Output
(CFM Approx) Motor
435 3440 RPM
Temperature
Control
Built-In Thermostat
Size
L x W x H (Inches)
25 x 9.4 x 15.5
(63.5 x 23.9 x 39.4 cm)
tially hazardous situation which, if not
avoided, COULD result in death or serious
injury.
CAUTION
situa tion which, if not avoided, MAY
result in minor or moderate injury.
IMPORTANT: Not every possible cir-
cumstance that might involve a hazard
can be anticipated. The warnings in this
manual and on tags or decals affixed to
the unit are therefore not all-inclusive.
If a procedure, work method, or oper-
ating technique not specifically recom-
mend ed by is used, you must make sure
it is safe for you and others.
You should also ensure that equipment
will not be damaged or made unsafe by
the operating or maintenance method
you choose.
Consumer: Retain this manual for future
reference.
RMC-FA150NGDGD
Electric Motor
Input Amperage
120V/60Hz, 1/9 HP 0.7
Indicates a poten­
tially hazardous
PROFESSIONAL GRADE
IMNGF150DGD - GBW
