VHS110N1 CR

Vacuum Cleaner Parts and Labels

1. Data plate which includes:
• Manufacturer's name and address
• Technical specifications
• Serial number
• Year of manufacture
• Weight (kg)
2. Panel power plate
Indicates that the panel must only be powered by the
voltage indicated on the data plate.
3. Inlet
4. Air Outlet
5.
Manual motor starter
6. Motorhead
7. Band latches
8. Container release handle
9.
Float for stopping liquids (optional)
10. Container for liquids
11. Inlet container for liquids
12. Lid
This vacuum cleaner creates a strong air flow which is drawn
in through the inlet (4) and blows out from the motor head
cover (5).
Before turning the vacuum cleaner on, fit the vacuum hose
into the inlet and then fit the required tool on the end of the
hose. After the hose and tools have been fitted, make sure
that the motor turns correctly.
The vacuum cleaner is equipped with a main filter which
enables it to be used for the majority of applications.
Besides the main filter which retains the more common
types of dust, the vacuum cleaner is fitted with an upstream
absolute (HEPA) filter with a higher filtering capacity for fine
dust and substances harmful to health.
US
Vacuuming of liquids (Optional)
The machine vacuums liquids and deposits them into the
container.
When the machine vacuums liquid materials must be
equipped with an optional float for stopping liquids (9).
The floater stopping liquids requires a dedicated bin (10) with
apposite inlet (11).
Before turning on the vacuum cleaner close the top inlet with
the apposite lid (12) and fit the vacuum hose into the inlet then
fit the required tool on to the other end of the hose (refer to
the manufacturer's accessory catalog or Service Center).
The float (9) stops the vacuuming operation (the vacuuming
units remain activated) when the liquid container (10) is full; it
is then necessary to turn off the vacuum cleaner and to empty
the liquid container (10).
The vacuum cleaner does not shut off automatically.
C424

Vacuum cleaner description

Figure 1

Optional kits

Please contact the manufacturer's sales network for
information on options.
Instructions for installing the options are included in the
conversion kit.
WARNING!
Use only genuine optional kits supplied and
authorized by the manufacturer.
Optional kits must be installed by Nilfisk qualified
personnel.

Accessories

Various accessories are available; refer to the manufacturer's
accessory catalog.
WARNING!
Use only genuine accessories supplied and authorized
by the manufacturer.

Packing and unpacking

Dispose of the packing materials in compliance with the laws
in force.
MODEL A
mm
VHS110N1 CR 700
* Weight with packaging

Unpacking, moving, use and storage

Operate on flat, horizontal surfaces.
The load-bearing capacity of the surface the vacuum cleaner
is placed on must be suitable for bearing its weight.
4
Figure 2
B C
kg (*)
mm mm
790 1440 53
