SECTION 3 |
Fig. 3.1 – SAM-1000-12
Fig. 3.2 – SAM-1500-12
3
Fig 3.3 – SAM-2000-12, SAM-3000-12
3
LeGenD
1. oN/off Switch
2. NeMA5-15r AC outlet
3. Modular Jack for remote Control
SAM-rC (optional)
4. 15A Circuit breaker
5. YELLOW LED - "Input Fault"
6. GREEN LED - "Power"
6 | SAMLEX AMERICA INC.
Layout
8
1
5
6
7
2
2 3
8
1
7
6
5
2
8
4
1
7
6
6
5
2
11
9
11
9
11
7. RED LED - "Fault"
8. Cooling Air Intake Slots
9. opening for fan Air Discharge
10. Positive battery Input Terminal
(with cover)
11. Negative battery Input Terminal
(with cover)
10
10
10
9
