Fault Code - INFOSEC E4 LCD Pro TM 10k Manuel Utilisateur

LCD display
Description
Battery Test
LCD display
Description
Warning status
LCD display
Description
Fault status
LCD display

3-8. Fault Code

Fault
DC Bus start failure
DC Bus over
DC Bus under
DC Bus unbalance
Inverter soft start failure
High Inverter circuit voltage
INFOSEC UPS SYSTEM – 15, Rue du Moulin – 44880 Sautron – France – www.infosec-ups.com
53
Hot Line Tel : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr – 11 16 AA XX 201 07
When the UPS is in AC mode or CVCF mode, press the "Test" key for
more than 1s. Then, the UPS will beep once and start the "Battery Test".
The line between I/P and the inverter icons will blink to remind the users.
This operation is used to check the status of the batteries.
When the UPS signals a warning and can work normally, the LCD
panel will display warning codes. Each warning code represents a
warning condition. Refer to section 3-9 to identify the situation.
When the UPS is in fault, it will display fault codes on the LCD panel.
Fault code Icon
01 None Low Inverter circuit voltage
02 None
03 None
04 None
11 None
12 None
Fault
Inverter circuit output short
circuited
Battery SCR short-circuited
Over temperature
Overload
Fault code Icon
13 None
14
21 None
41 None
43
