Hatco Glo-Ray GPS Série Manuel D'installation Et D'utilisation page 15

English
Apply a bead of NSF-approved sealant between the
countertop and the mounting flange on the unit. Sealant
must be rated for use at a minimum temperature of 250° F (121° C).
Z-Bracket
Bracket Screw
Model Minimum Width
GRSB-24-F
GRSB-24-I
GRSB-24-O
GRSB-30-F
GRSB-30-I
GRSB-30-O
GRSB-36-F
GRSB-36-I
GRSB-36-O
GRSB-42-F 42-1/2" (1080 mm)
GRSB-42-I 42-1/2" (1080 mm)
GRSB-42-O 42-1/2" (1080 mm)
GRSB-48-F 48-1/2" (1232 mm)
GRSB-48-I 48-1/2" (1232 mm)
GRSB-48-O 48-1/2" (1232 mm)
GRSB-54-I 54-1/2" (1384 mm)
GRSB-60-F 60-1/2" (1537 mm)
GRSB-60-I 60-1/2" (1537 mm)
GRSB-60-O 60-1/2" (1537 mm)
GRSB-66-F 66-1/2" (1689 mm)
GRSB-66-I 66-1/2" (1689 mm)
GRSB-72-F 72-1/2" (1842 mm)
GRSB-72-I 72-1/2" (1842 mm)
GRSB-72-O 72-1/2" (1842 mm)
Form No. GRSM-0318
Countertop Cutout — GRSB Models
Maximum Width
24-1/2" (622 mm) 24-3/4" (629 mm)
24-1/2" (622 mm) 24-3/4" (629 mm)
24-1/2" (622 mm) 24-3/4" (629 mm)
30-1/2" (775 mm) 30-3/4" (781 mm)
30-1/2" (775 mm) 30-3/4" (781 mm)
30-1/2" (775 mm) 30-3/4" (781 mm)
36-1/2" (927 mm) 36-3/4" (934 mm)
36-1/2" (927 mm) 36-3/4" (934 mm)
36-1/2" (927 mm) 36-3/4" (934 mm)
42-3/4" (1086 mm)
42-3/4" (1086 mm)
42-3/4" (1086 mm)
48-3/4" (1238 mm)
48-3/4" (1238 mm)
48-3/4" (1238 mm)
54-3/4" (1391 mm)
60-3/4" (1543 mm)
60-3/4" (1543 mm)
60-3/4" (1543 mm)
66-3/4" (1696 mm)
66-3/4" (1696 mm)
72-3/4" (1848 mm)
72-3/4" (1848 mm)
72-3/4" (1848 mm)
GRSB Model Installation
Minimum Depth
30-1/2" (775 mm)
30-1/2" (775 mm)
30-1/2" (775 mm)
30-1/2" (775 mm)
30-1/2" (775 mm)
30-1/2" (775 mm)
30-1/2" (775 mm)
15
INSTALLATION
Mounting Screw
Maximum Depth
16" (406 mm) 16-1/4" (413 mm)
20" (508 mm) 20-1/4" (514 mm)
30-3/4" (781 mm)
16" (406 mm) 16-1/4" (413 mm)
20" (508 mm) 20-1/4" (514 mm)
30-3/4" (781 mm)
16" (406 mm) 16-1/4" (413 mm)
20" (508 mm) 20-1/4" (514 mm)
30-3/4" (781 mm)
16" (406 mm) 16-1/4" (413 mm)
20" (508 mm) 20-1/4" (514 mm)
30-3/4" (781 mm)
16" (406 mm) 16-1/4" (413 mm)
20" (508 mm) 20-1/4" (514 mm)
30-3/4" (781 mm)
20" (508 mm) 20-1/4" (514 mm)
16" (406 mm) 16-1/4" (413 mm)
20" (508 mm) 20-1/4" (514 mm)
30-3/4" (781 mm)
16" (406 mm) 16-1/4" (413 mm)
20" (508 mm) 20-1/4" (514 mm)
16" (406 mm) 16-1/4" (413 mm)
20" (508 mm) 20-1/4" (514 mm)
30-3/4" (781 mm)
Metallic
Countertop
