ACCESSORIES

Hex key
Extension pole
Only use the appropriate accessories intended for this
tool. Accessory information can be found on the product
packaging, at a Worx dealer or on our website at www.
worx.com.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
Intend Use
This attachment is intended for sawing of trees, tree
trunks, branches, limbs, etc. Cuts can be sawed with
or across the grain. This product is not suitable for
sawing mineral materials.
ASSEMBLY & OPERATION
Action
ASSEMBLY
10
Connecting
Remove the existing attachment, and
connect the pole saw attachment. Slip
the attachment into the shaft of the
main unit and secure in place with the
locking knob.
Place the saw on a solid, level surface
before assembling. Before using,
make sure it is well connected
WARNING! Do not install the
battery pack before it has been
completely assembled.
Always use gloves when handling
the chain.
Removing the bar and chain sheath.
Pole saw attachment
TENSIONING CHAIN
Place the saw on any suitable
flat surface. And turn the Chain
WA0222
Tensioning Knob clockwise until it is
hand tight.
1
NOTE: The tension is automatically
1
increased while the Chain Tensioning
Knob is being turned in a clockwise
direction.
WARNING: The chain is not
yet tensioned. Tensioning the
chain applies as described under
"TENSIONING CHAIN". The chain
now needs to be inspected to make
sure it is properly tensioned.
NOTE: New saw chains will stretch.
Check the chain tension frequently
when first used and tighten when
the Chain becomes loose around the
Guide Bar.
WARNING:
• Removing the battery pack
before adjusting saw chain
tension.
• Cutting edges on chain are
sharp. Use protective gloves
when handling chain.
• Maintain proper chain tension
Figure
always. A loose chain will
increase the risk of kickback.
A loose chain may jump out of
guide bar groove. This may injure
operator and damage chain. A
loose chain will cause chain, bar,
and sprocket to wear rapidly.
NOTE: The Chain is properly
tensioned when it can be lifted off
of the Guide Bar and the drivelink is
See Fig. A
within the rail of the Guide Bar.
NOTE: The Chain will stretch while
cutting and lose proper tension. When
the chain becomes loose, completely
unscrew the Chain Tensioning Knob,
that is, to turn it in a counter-clockwise
direction. And retighten it again.
See Fig. B
Assembling the extension pole to
the machine
Connecting the extension pole to the
pole saw.
NOTE: Make sure the extension
pole is locked into position
securely before operation.
Attaching the shoulder strap
Attach the shoulder strap to the
hook on the pole with the included
carabiner hook.
See Fig. C
See Fig. D
See Fig. E
