Please also refer to the instructions for your primary Z-Wave-Controller!
SKU: ABUS CFA3010
Quickstart
This is a secure Door Lock for
Europe. To run this device please
insert fresh 4 * AA batteries. Please
make sure the batteries are fully
charged. The quickstart can only
take place if the door lock has been
installed and the road and motor
drive has been carried out (see
page 34-42). Attention: the delivery
status of the Z-Wave lock drive is
the S2 security standard. Please
contact the manufacturer of your
Z-Wave-Controller for information
on the security standard used (S0
or S2) an set this in advance on
the drive in accordance with your
Z-Wave-Controller.
First, start the Inclusion process
at your primary Z-Wave-Controller.
Then press the two arrow keys on
the drive for 3 seconds, until the left
LED lights up green. This indicates
the management mode. Clicking
on the 'Lock' button includes the
device. Now both LEDs flash green
at the same time. This indicates that
the device is ready for inclusion. If
the inclusion is successful, the right
green LED and the flashing stops.
The inclusion mode is terminated.
Pressing the 'Open' key also ends
the management mode. Please
observe the instructions on the
central controller when embedding.
The device also supports Smart
Start. Please scan the QR code on
the cover or on the device and your
controller will add the device auto-
matically when powered up.
What is Z-Wave?
Z-Wave is the international wireless
protocol for communication in the
Smart Home. This device is suited
for use in in the region mentioned
in the Quickstart section. (For more
information about frequency regu-
CFA3010 Z-Wave6.indd 27

Possible uses and important information

lations please refer to the frequency
coverage overview at http://ma-
nuals.z-wave.info/frequencies.php).
Z-Wave ensures a reliable com-
munication by reconfirming every
message (two-way communication)
and every mains powered node can
act as a repeater for other nodes
(meshed network) in case the recei-
ver is not in direct wireless range of
the transmitter.
This device and every other certified
Z-Wave device can be used together
with any other certified Z-Wave
device regardless of brand and
origin as long as both are suited for
the same frequency range.
If a device supports secure com-
munication it will communicate
with other devices secure as long as
this device provides the same or a
higher level of security. Otherwise
it will automatically turn into a
lower level of security to maintain
backward compatibility.
A secure connection to the device
according to security standard S2 re-
quires the network key type „access
device".
For more information about Z-Wave
technology, devices, white papers
etc. please refer to www.z-wave.
info.
Product Description
The HomeTec Z-Wave wireless door
lock actuator is system designed for
retrofitting to doors that open in-
wards to provide motorised locking
and unlocking functions. The door
can be electronically operated using
local buttons and any Z-Wave device
capable to control door locks. For
the wireless door lock actuator to
work, the cylinder must project 7-12
mm on the inside of the door (plus
the thickness of the fitting or col-
lar). Because the actuator operates
