Drip off time
Delay for fan start after defrost
Fan start temperature
Fan cutin during defrost
Defrost sensor: 0 =Stop on time, 1=S5, 2=S4, 3=Sx
(Application 1-8 and 10: both S5 and S6.
Application 9: S5 and S5B)
Pump down delay
Drain delay (used at hot gas defrost only)
Max. aggregate refrigeration time between two defrosts
Heat in drip tray. Time from defrosting stops to heating
in the drip tray is switched off
Extra defrost with adaptive function allowed:
0=none, 1=monitoring only, 2=Day only, 3=Both day
and night, 4=Night only
Reset of the "Adaptive defrosting function" (starts a
defrost and starts subsequent new tuning)
Injection control function
Injection algorithm
Only for trained personnel
Max. value of superheat reference
Min. value of superheat reference
MOP temperature. Off if MOP temp. = 15.0 °C
Glide for Ezotrope refrigerant (at S1-measurement only)
Period time of AKV pulsation
Only for trained personnel
Injection algorithm
Only for trained personnel
Injection algorithm
Only for trained personnel
Injection algorithm
Only for trained personnel
Injection algorithm
Only for trained personnel
Injection algorithm
Only for trained personnel
Injection algorithm
Only for trained personnel
Selection of signal to superheat measurement: 1=
pressure transmitter AKS32R, 2= Temperature sensor S1
Fan
Fan stop temperature (S5)
Pulse operation on fans: 0=No pulse operation, 1=At
thermostat cuts out only, 2= Only at thermostat cut
outs during night operation
Period time for fan pulsation (on-time + off-time)
On-time in % of period time
Real time clock
Six start times for defrost.
Setting of hours.
0=OFF
Six start times for defrost.
Setting of minutes.
0=OFF
Clock - Setting of hours
Clock - Setting of minute
Clock - Setting of date
Clock - Setting of month
Clock - Setting of year
Miscellaneous
Delay of output signals after start-up
AK-CC 550
Code 1 2 3
d06 1 1
d07 1 1
d08 1 1
d09 1 1
d10 1 1
d16 1 1
d17
d18 1 1
d20
d21 1 1
d22 1 1
n05 1 1
n09 1 1
n10 1 1
n11 1 1
n12 1 1
n13 1 1
n15 1 1
n16 1 1
n17 1 1
n18 1 1
n23 1 1
n24 1 1
n57 1 1
F04 1 1
F05 1 1
F06 1 1
F07 1 1
t01 1 1
- t06
t11 1 1
- t16
t07 1 1
t08 1 1
t45 1 1
t46 1 1
t47 1 1
o01 1 1
