6. Operation
6.1 Charging the battery (Fig. 1)
1. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Plug the battery charger in the plug
socket and connect the charging cable to the
charging connection. The charging process
starts as soon as the charging cable is
connected to the charging adapter.
2. The red LED (6) will come on to indicate that the
battery pack is being charged.
Important! It does not switch off automatically
when fully charged!
Disconnect the charge cable from the screwdriver
after charging.
Important! The handle may become a little warm
during the charging process. This is normal.
If the battery pack fails to charge, please check
whether there is voltage at the socket-outlet
and check for proper contact with the charging
contacts in the battery charger.
If the battery still fails to charge, send
the battery charger
and the screwdriver
to our customer services department.
Timely recharging of the battery pack will help it
serve you well for a long time. You must recharge
the battery pack when you notice that the power of
the screwdriver drops.
Never allow the battery pack to become fully
discharged. This will cause it to develop a defect.
6.2 ON/OFF changeover switch (Fig. 2/Item 2)
You can select between clockwise and counter-
clockwise rotation.
Change the direction of rotation only when the
equipment is at a standstill. If you fail to observe this
point, the gearing may become damaged.
6.3 Angle setting (Fig. 1/Item 5)
The screwdriver can be locked into 3 different angle
settings. To do so, press the locking button (5) and
move the screwdriver into the desired position. Then
release the locking button (5).
Important. Before you switch on the screwdriver,
make sure that it is correctly locked in the angle
position in question.
18.03.2008 8:20 Uhr Seite 9
6.4 Changing the tool (Fig. 3)
Important!
Insert the bit (A) into the bit chuck (1).
To remove the bit (A), pull it back out of the bit chuck
(1).
6.5 Screwdriving
We recommend using self-centering screws (e.g.
Torx screws, recessed head screws) designed for
reliable working. Be sure to use a bit that matches
the screw in shape and size. Set the torque, as
described elsewhere in these operating instructions,
to suit the size of screw.
7. Cleaning, maintenance and ordering
of spare parts
Always pull out the mains power plug before starting
any cleaning work.
7.1 Cleaning
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
We recommend that you clean the device
immediately each time you have finished using it.
Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts
of the equipment. Ensure that no water can seep
into the device.
7.2 Maintenance
There are no parts inside the equipment which
require additional maintenance.
7.3 Ordering replacement parts
Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info
