Reattaching The Refrigerator Doors - Samsung Rf323Te Manuel D'utilisation

With the door opened
1. Remove 3 screws holding down the TOP
TABLE ( 1 ) and separate wires connected.
2. Disconnect two connector (
door. To remove the water coupler from the
hinge, twist and pull it from the hinge. Remove
the water line ( 3 ) while pressing the marked
part ( 4 ) of the water line coupler.
If a red clip is on the coupler, it must be
CAUTION
removed before removing the tube.
2
Red Clip Red Clip
(1/4") (1/4")
3
4
3. Pull and remove the hinge lever (
the ground screw ( 6 ) attached to the upper
left door hinges with a philips screwdriver (+).
Remove the upper left and right door hinges ( 7 ).
5
7
4. Lift the door straight up to remove.
08_ setting up
DA68-02603A.indb 08 DA68-02603A.indb 08
5. Remove the screw (
lower left and right door hinges with a philips
screwdriver (+). Remove the 2 hex head bolts
( 9 ) attached to the lower left and right door
hinges with an allen wrench (3/16"). Remove
the lower left and right door hinges ( 10 ).
1
2 ) on the left side
REATTACHING THE
REFRIGERATOR DOORS
To reattach the fridge doors after you have moved
the fridge to its fi nal location, assemble the parts
in reverse order.
1. The Water Line must be fully Inserted to the
center of transparent coupler to prevent water
leakage from the dispenser.
2. Insert
holds the line fi rmly.
5 ) . Remove
6
DISASSEMBLE THE FLEX DOOR
1. Take out the upper drawer by lifting it up.
2. Remove the freeze room guard (
the guard up.
8 ) attached to the
10
8
9
Allen wrench Allen wrench
the clip in the install pack and check that it
Center of transparent Center of transparent
clip A (1/4") clip A (1/4")
(6.35mm) (6.35mm)
1
coupler coupler
1 ) by lifting
