2. Installation
See P1, P2 on page 1:

Take out the appliance and accessories from the packing box, check the accessories
and whether the appliance enclosure is well-found or not. (picture 1 and 2).

Click the wheels in the dedicated holes (see P6)

Push the flexible hose in the air inlet opening (see P7a) and turn clock-wise to lock the
hose.

Insert the other end (= the handle) of the flexible hose into the rigid tube see P7b.

Depending on required job: choose the correct accessory and connect the rigid tube and
the accessory together.
o Crevice nozzle (Picture 4a): ideal for narrow spaces
o Round Brush (picture 4b) : ideal for cleaning furniture or counter top
o Floor brush (Picture 3a and 3b): ideal for cleaning the floor

Loosen the lock and take the top cover 7 from the container barrel 1.
For vacuuming DRY dust:
o Attach the filter (WDZ510: item A / WDZ520 item A / WDZ530 item A+B)
o P8: shows how to mount the non woven filter (A)
o P9: shows the compartment where the HEPA filter (B) or Sponge filter (C) is
to be mounted
o P10: shows how the HEPA filter (B) is mounted
For vacuuming LIQUIDS:
o Mount the sponge filter "C" to the compartment as shown in P9.
o P9: shows the compartment where the HEPA filter (B) or Sponge filter (C) is
to be mounted
Do NOT mount the non woven filter (A) nor the HEPA filter (B). Filters
o
A and B should only be mounted when vacuuming dry dust!
All models:

Mount the top cover 7.

Close the locks

Insert the power cord plug in the wall socket.
The Vacuum cleaner is now ready to use.

Press the on/off switch 5 to switch it on.
