LEROY-SOMER
Designation
B 31/32 or B 33/34
Bma 31/32 or Bma 33/34
BmaVaR 31/32 or BmaVaR 33/34
cVI Vma 31/32 or cVI Vma 33/34
esFR Vma 31/32 or esFR Vma 33/34
RF100 – RF200 – RF600
RF – BRR – 800 – 200
PX lcD
coD Vma 33/34
Vma soFt
PaD Vma 31/32 or PaD Vma 33/34
PX KeY
Vma com PB 33/34
Vma com Is 33/34
Vma com Dt 33/34
Vma com cn 33/34
Flt Vma 31-32m 110/Flt Vma 32m 150
Flt Vma 31/32t 220/Flt Vma 32t 400
Flt Vma 33
Flt Vma 34

1.3 - Characteristics

1.3.1 - Electrical data

Power supply
Phase voltage imbalance
output voltage
Power range (kW)
maximum number of
power-ups per hour
*0.55 kW max. for 115 V supply
**7.5 kW max. for 230 V supply
1.3.2 - Characteristics and functions
Characteristics
motor frequency variation
range
efficiency
overload
InstallatIon anD maIntenance
VARMECA 30
Variable speed motor or geared motor
OPERATING EXTENSIONS
Integrated speed control knob
speed control knob and integrated run-stop control knob
speed control knob and integrated stop forward/reverse control knob
Integrated speed control
Brake control
Braking resistor Power 100, 200 and 600 W
Braking resistor Power 800 W – external mounting
Parameter-setting console
encoder feedback
Parameter-setting software
local display unit
copy key
Fieldbus: PRoFIBUs DP
Fieldbus: InteRBUs s
Fieldbus: DeVIcenet
Fieldbus: can oPen
emc filter for residential environment – Filter for the single phase range
emc filter for residential environment – Filter for the Vma 31/32 three phase range
emc filter for industrial environment – mounting for Vma 33 tl/t
emc filter for industrial environment – mounting for Vma 34 tl/t
single-phase supply
110V -10 % to 120V +10 % 50-60Hz ± 2 %
200V -10 % to 240V +10 % 50-60Hz ± 2 %
-
From 0 V to input voltage
0.25 - 0.37 - 0.55* - 0.75 - 0.9 - 1.1 - 1.5
10
- 10 to 80 Hz at constant torque (factory setting can be modified with parameter-setting option)
- 10 to 50 Hz for general applications (factory setting can be modified with parameter-setting option)
- 0 to Fmax depending on thermal and mechanical limits (Fmax = 400 Hz ; leRoY-someR to
be consulted anytime the applications requires the drive to run at more than 150 Hz)
97.5% motor efficiency
150% of In for 60 s
10 times per hour
Description
3-phase supply
200V -10 % to 240V +10 % 50-60Hz ± 2 %
380V -10 % to 480V +10 % 50-60Hz ± 2 %
3%
From 0 V to input voltage
0.25 - 0.37 - 0.55 - 0.75 - 0.9 -1.1 - 1.5 - 4 -
5.5 - 7.5** - 9 - 11
100
VARMECA 30
