Master Clock Connections - Simplex 100 Manuel D'utilisation

The S100 series clock can operate in the following master clock configurations:
SLAVE - The S100 series clock receives 24 VDC Simplex 58th-Minute corrections from a master
clock.
Master
Clock
SLAVE - The S100 series clock receives 115VAC Simplex 58th-Minute corrections from a master
clock
115VAC
Master
Clock
SYNC.
MASTER - The S100 series clock transmits 58th-minute corrections.
Simplex
100 as
Master
OUT +
OUT -
Simplex
Bell/Sync.
Option
OUT+
OUT-
Simplex
IN +
100
Slave
IN -
IN+ Simplex
100
IN - Slave
Simplex
IN+
100
Slave
IN-
