The version with a flexible/spiral cable does not lock/unlock the Homebox.
The button or autostart operation is used instead of the scan point; with this version no back
office check is needed to start the system.

24. TECHNICAL SPECIFICATIONS

Number of charging points:
Power output:
Socket:
Flexible coiled cord:
Protocol:
Back office protocol :
Positioning:
Communication:
Suitable charge cards:
Connection value:
Output voltage:
Total weight: with socket:
Casing dimensions HxWxD:
Casing material:
Standard colour:
Water resistance:
Vandalism resistance:
Treatment:
Operating/ambient temperature:
Earth leakage protection:
AC meter:
Maximum cable thickness:
Pay attention ! Earthing (earth dispersion resistance) completely
Ecotap® B.V. reserves the right to change the above technical data without prior notice as
a result of continued innovative development of the charging system. Please note also that
the technical data may vary between countries.
22. www.ecotap.nl
in accordance with the applicable standards.
1
22 kW
Type 2
Type 1 of Type 2
Mode 3
OCPP 1.6 Json
GPS (with registration)
GSM Modem / Controller with RFID-reader
(with registration)
Mifare, NTag and iCODE SLI cards (
info )
1x 16A tot 3x 32A
230 V/ 400 V 50 Hz
with socket: 10 Kg, with coiled cord: 12 Kg
530 mm x 220 mm x 200 mm
Steel 2,2 mm
RAL 7011/RAL 9016
IP 54
IK 10
Anti-corrosion and powder coating
-25°- tot 60°
Type B (optional)
MID certified
25 mm2
more
