3-4 Determine the location where the cabling will enter the
remote controller (back, left side, top left, top center).
3-4-1 Back outlet
Cut off resin area (hatched area).
3-4-3 Top left outlet
Using an appropriate tool, cut the plastic at
the hatched area and remove any remaining
burrs.
3-5 Install wiring.
NOTE
1. Switch box and control wiring are not attached.
2. Do not touch the remote controller PC-board.
Wiring Specifi cations
Wiring Type Non-shielded, 2-conductor, stranded copper cable
Wiring Size AWG-18
Wiring Length Maximum 1640 feet (500m)
English
3-4-2 Left outlet
Using an appropriate tool, cut the plastic at
the hatched area and remove any remaining
burrs.
3-4-4 Top center outlet
Using an appropriate tool, cut the plastic at
the hatched area and remove any remaining
burrs.
