You have purchased an air compressor unit consisting
of a one cylinder, single-stage air compressor pump
and air tank.
This air compressor requires no oil. Now you can enjoy
all the benefits of having an air compressor without
ever having to purchase, add or change oil.
Your air compressor can be used for operating paint
spray guns, air tools, blow guns, nailers/staplers, air
CFM: Cubic Feet per Minute.
SCFM: Standard Cubic Feet per Minute; a unit of
measure of air delivery.
PSI: Pounds per Square Inch; a unit of measure of
pressure.
ASME: American Society of Mechanical Engineers;
made, tested, inspected and registered to meet the
standards of the ASME.
Cut-In Pressure: While the motor is off, air tank
pressure drops as you continue to use your accessory.
When the tank pressure drops to a certain low level
and the pressure switch lever is in "Auto", the motor
will restart automatically. The low pressure at which
the motor automatically restarts is called "cut-in
pressure."
Model No.
Number of Cylinders
Bore
Stroke
Voltage - Single Phase
Minimum Branch Circuit Requirement
Fuse Type
Amperage at Maximum Pressure
Air Tank/Capacity
Approximate Cut-in Pressure
Approximate Cut-out Pressure
SCFM @ 40 psi
SCFM @ 90 psi
D21794

GENERAL INFORMATION

brushes, and inflator kits. An air pressure regulator is
required for most of the applications.
An inline air filter which removes moisture and dirt from
compressed air should be used where applicable.
An inline regulator can be used if a more precise
adjustment of air pressure is needed downstream.

GLOSSARY

Cut-Out Pressure: When you turn on your air com-
pressor and it begins to run, air pressure in the air tank
begins to build. It builds to a certain high pressure
before the motor automatically shuts off - protecting
your air tank from pressure higher than its capacity.
The high pressure at which the motor shuts off is called
"cut-out pressure."
CSA: Electrical products sold in Canada are required
to be certified to the applicable CSA standard (s).
Canadian Standards Association (CSA) is a standards
writing and safety testing organization. Products that
are CSA certified have been evaluated and tested and
found to meet or exceed the applicable CSA standard
(s) for safety and electrical performance.

SPECIFICATION CHART

6 — ENG
919.727270
2
2 3/8"
1.2"
240
15 amps
Time Delay
15.0
ASME/60 gal. (U.S.)
100
130
14.2
9.9
