Hardware/Software Requirements

TI-Presenter is designed to provide video output in two TV formats –
Make sure your TV supports one of these formats.
To use your TI-Presenter, you must have the following:
•
A ViewScreen calculator.
•
An NTSC or
A composite Video-In port and the ability to switch from TV channels to video
♦
input mode.
-or-
A VCR with a composite Video-In port.
♦
-or-
An RF (regular antenna connection) port and an RF modulator.
♦
Many PAL TVs are equipped with a SCART Video-In port (Europe only). If that is the
case, use the enclosed SCART adapter.

Setting up Your TI-Presenter

Refer to the drawing below when setting up your TI-Presenter. Step-by-step
instructions are given on the following pages.
PAL TV with:
Figure 1. Cable and unit connection
TI-Presenter User Guide
NTSC and PAL .
3 ENG
