GB Setting of the end positions

4.3. Mechanic requirements

Operating of the SE Plus-R and SEL Plus-R drives is possible with normal safety and
fixing springs. Optionally, security springs can also be used.
For operating the SES-R security springs must be used.
If the drive is supposed to move against the stop in the upper end position, a stable
end stop must be installed!
If the drive is set in automatic setup-mode, a limit must be installed for the lower switch-
off position (e.g. windowsill) for the shutter to run against.

4.4. Selection table for settings:

Setup-mode/end positions in
operation
4.4.1 Automatic setup-mode bottom
position, top stop/release
4.4.2 Manual setup-mode bottom
position, top position
4.4.3 Manual setup-mode bottom
position, top stop/release
4.4.4 Manual setup-mode bottom
position, top stop/no release
The abbreviations for the settings types and order:
uA = move to stop at bottom
uP = store bottom position
oA = move against stop at top
oP = store top position
o5cm = store top positon 5 cm before stop
SE Plus SEM Plus SEL Plus
X
uP+oP
X X
uP+oA uP+oA
X
uP+o5cm
30
SES
X X
oA+uA oA+uA
X X
uP+oP uP+oP
X X
uP+oA uP+oA
