OPERATION |

STAND-ALONE OPERATION

Connect the unit to suitable mains supply.
Ensure Remote Humidistat switch is set in the 'OFF' (O) position.
Switch Power switch to the 'ON' (I) position.
The fan will start and the Ammeter reading will rise. The ammeter indicates the current taken by the PTC
heater bank. Its reading will depend on the 'Process' air temperature and the 'Regen' airflow. Typically, it will
indicate between 2 and 3 amps (EPD150/EPD150-PRO) or between 4 and 6 amps (EPD200/EPD200-PRO), this
will reduce if the airflow is low or the 'Process' air temperature is high.

REMOTE OPERATION

For remote operation it is necessary to connect a switch or humidistat via the 'Remote Humidistat Connector'
which can be accessed by removing the dust cap. A connection plug is available on request.
ATTENTION: The remote connector is mains voltage!
The remote switch/humidistat should be connected between pins 1 and 3.
The earth pin is connected to ground and can be used if required (see wiring diagram).
The Remote Humidistat switch should be set to the 'ON' position.
The unit will now operate according to the state of the remote switch.

AIR FILTER

The unit has an inlet air filter, this should be checked periodically and if necessary cleaned. It can be cleaned
with a vacuum cleaner or washed in mild detergent.
ATTENTION:
Do not run the unit without a filter fitted as dust will impair the performance of the Desiccant Rotor.
