Speciications

TV BROADCASTING
PAL/SECAM B/G D/K K' I/I' L/L'
RECEIVING CHANNELS
VHF (BAND I/III)
UHF (BAND U)
HYPERBAND
NUMBER OF PRESET CHANNELS
1000
CHANNEL INDICATOR
On Screen Display
RF AERIAL INPUT
75 Ohm (unbalanced)
OPERATING VOLTAGE
220-240V AC, 50 Hz.
AUDIO
German + Nicam Stereo
AUDIO OUTPUT POWER (W
2 x 8
POWER CONSUMPTION (W)
150 W (max)
PANEL
16:9 display, 40" Screen Size
DIMENSIONS (mm)
DxLxH (With foot): 221 x 956 x 606
Weight (Kg): 15,00
DxLxH (Without foot): 40 x 956 x 569
Weight (Kg): 13,00
) (10% THD)
RMS.
English - 72 -

Digital Reception (DVB-T)

Transmission Standards:
DVB-T, MPEG2, DVB-T, MPEG4 HD
I. DEMODULATION
• Symbol rate: COFDM with 2K/8K FFT mode.
• Modulation: 16-QAM - 64-QAM FEC for all DVB
modes (automatically found)
• MHEG-5 ENGINE compliant with ISO/IEC 13522-5
UK engine Proile (UK only)
• Object carousel support compliant with ISO/IEC
135818-6 and UK DTT proile(UK only)
• Frequency range: 474-850 MHz for UK models
II. VIDEO
• H.264 (MPEG-4 part 10) main and high proile level
4.1/MPEG-2 MP@HL video decoder.
• HD display multi format capable (1080i, 720p,
576p)
• CVBS analogue output.(In HD channels, this will
not be available
III. AUDIO
• MPEG-1 layer I/II, MPEG-2 layer II, AAC, HEAAC,
AC3, E-AC3
• Sampling frequencies supported are 32, 44.1 &
48 kHz

Digital Reception (DVB-C)

Transmission Standards:
DVB-C, MPEG2, DVB-C, MPEG4
i. DEMODULATION
-Symbolrate: 4.0 Msymbols/s to 7.2 Msymbols/s
- Modulation: 16-QAM , 32-QAM ,64-QAM, 128-QAM
and 256-QAM
ii. VIDEO
- All MPEG2 MP@ML formats with up-conversion and
iltering to CCIR601 format.
-CVBS analogue output
iii. AUDIO
-All MPEG1 Layer 1 and 2 modes
-Sampling frequencies supported are 32, 44.1 & 48
kHz.
