Replacing The Led Lamp; Breakdown - Inventum AKV6004RVS Mode D'emploi

REPLACING THE LED LAMP

When a LED lamp in the cooker hood is defective, you are not able to replace it yourself. Observe these steps:
• Remove the plug from the socket or interrupt the power supply by switching off the fuse in the group box.
• Remove the metal fat filters and press the lamp holder downwards from the inside - figure 1.
• Turn the defective LED lamp clockwise out of the holder - figure 1. Replace the broken LED lamp by a similar type (3.0 W LED spot).
• Turn the broken LED lamp anti-clockwise into the holder - figure 2. The lamp will spring back in the correct position by itself. If this
does not happen by itself, you can carefully bend the holder back, so that the LED lamp is in the correct position again.
• Place the metal fat filters back and insert the plug in the socket.
1 2
6

breakdown

What to do in case of problems with your cooker hood? Based on the solutions below, check whether you can resolve the problem
yourself before contacting the Inventum customer service.
The motor no longer functions?
• Is the plug properly inserted in the socket?
• Is there a power failure?
• Is one of the fuses defective in the meter cupboard?
The cooker hood does not extract properly/makes more noise.
• Are the dimensions of the discharge in order?
• Is the discharge blocked?
• The discharge should be at least 150 mm. A small diameter could have a negative effect on the motor's suction power.
• Are the fat filters clean?
• Have the carbon filters not been replaced by more than 6 months? Replace the carbon filters.
• Is there sufficient air supply to replace the discharged air?
22
