AXIS P12 Series Installation Guide

Connect the cables

1. Optionally connect external input/output devices, e.g. alarm devices. See page 9 for information
on the terminal connector pins.
2. Connect the main unit to the network using a shielded network cable.
3. Connect the sensor unit to the main unit. If required, the cable can be shortened. See the User
Manual for further information.
4. Connect power, using one of the methods listed below:
• PoE (Power over Ethernet, Class 2). If available, this is automatically detected when the
network cable is connected.
• Connect power via the terminal connector. See page 9 for information on the terminal con-
nector pins.
5. Check that the indicator LEDs indicate the correct conditions. See the table on page 11 for
further details. Note that some LEDs can be disabled and may be unlit.
Page 19
