INSTALLATION
• 4 crimp connectors; blue, for connection cables from 1.5 mm
2.5 mm
• 3 crimp connectors; red, for signal cable – not relevant to Actun OPTI-QS.
The pump does not feature a signal connection!
• 1 casting mold with mold lid
• 1 container with casting resin (250 ml)
• 1 container with hardening fluid (100 ml)
• 1 wooden spatula for mixing
Using the sealing kit (Fig. 4)
Fig. 4.: Using the sealing kit
Connection cable on pump side
1
( p ower supply)
2 Connection cable (power supply)
3 Mold lid
4 Water level sensor
The pump cable has been prepared ready for installation and casting ex works. In this
context, the water level sensor has already been connected to the pump cable and the
mold lid has been positioned over the water level sensor.
Do not bend the water level sensor during the following steps to prevent damage or
change its position within the mold lid!
1. Insert the power supply connection cable through the large hole in the base of the cas-
ting mold until the end protrudes from the casting mold by approximately 100 mm.
2. Strip 50 mm of the cable sheaths on the connection cable.
3. Cut the individual wires of pump and connection cables to the specified lengths so that
associated, individual wires correspond accordingly.
4. Strip the ends of individual wires.
5. Connect the individual wires of pump and connection cables using the correspondingly
matching crimp connectors. Check that the connection is secure.
6. Add the full quantity of hardener to the casting resin and carefully stir using the enc-
losed wooden spatula.
7. Bring the casting mold to an upright position (connection cable at the bottom, pump
cable at the top) and secure it in this position so that the casting mold cannot tip over.
In this process, do not squeeze the casting mold.
8. Shake the casting resin mixture into the casting mold up to a fill level of approximately
10 mm below the mold opening.
9. Evenly pull the connection cable through the base of the casting mold until the mold
lid seals the casting mold. In this process, hold the pump cable and carefully feed it
through.
Installation and operating instructions Wilo-Actun OPTI-QS...
(AWG 13)
2
5 Crimp connector
6 Casting mold
7 Casting resin mixture with hardener
- -
(AWG 15) to
2
