ATTENTION
Damage to the rotor arm
The rotor arm can be damaged if it hits edges and cor-
ners.
Do not move the device over free-standing corners and
edges.
Illustration D
Note
● The T-Racer is not suitable for scraping or scrub-
bing.
● Test the device on an inconspicuous area before us-
ing on sensitive surfaces, e.g. wood.
● Do not allow it to remain in one area, but keep it in
motion.
1. Clean the floor surface by guiding the T-Racer over
the floor surface without exerting excessive pres-
sure.
Cleaning wall surfaces
1. Attach the T-Racer directly to the high-pressure gun.
a Press the bayonet connector of the T-Racer into
the connection on the high-pressure gun and
then turn by 90° until it latches into place.
b Tighten the union nut if present.
2. Clean the wall surface.

After use

Rinse off the device with a gentle water stream after
use.
 Detach the T-Racer and any extension tubes from
the high-pressure gun.
 Rinse off the T-Racer with the high-pressure gun
(without accessories) or wipe down with a damp
cloth.
Storage
Store the device in a frost-protected place.
Care and service
Removing/installing the nozzles
The described procedure applies to all nozzles on the
device.
Illustration E
1. Remove the clip.
2. Pull the high-pressure nozzle out.
3. Fit the high-pressure nozzle.
4. Fit the clip.
Cleaning the high-pressure nozzle
1. Remove the high-pressure nozzle.
2. Flush the high-pressure nozzle with clear water in
both directions. Replace a damaged high-pressure
nozzle where necessary.
3. Install the high-pressure nozzle.

Troubleshooting guide

High-pressure cleaner not building up pressure or
pulsing
High-pressure nozzles clogged or damaged.
1. Remove the high-pressure nozzles.
2. Check the high-pressure nozzles for clogging and
clean if necessary.
3. Check the high-pressure nozzles for damage and
replace if necessary.
4. Flush the T-Race with clear water without the noz-
zles fitted.
5. Install the high-pressure nozzles.
6
Incorrect high-pressure nozzle selected.
The device only provides optimum cleaning results
when used with the appropriate high-pressure nozzles!
1. Select the appropriate high-pressure nozzles ac-
cording to the high-pressure cleaner used.
2. Install the high-pressure nozzles.
The warranty conditions issued by our relevant sales
company apply in all countries. We shall remedy possi-
ble malfunctions on your appliance within the warranty
period free of cost, provided that a material or manufac-
turing defect is the cause. In a warranty case, please
contact your dealer (with the purchase receipt) or the
next authorised customer service site.
(See overleaf for the address)

Remarques générales.........................................

Illustrations et descriptions dans ce manuel d'uti-
lisation .................................................................
Utilisation conforme.............................................
Protection de l'environnement.............................
Accessoires et pièces de rechange ....................
Etendue de livraison............................................
Consignes de sécurité.........................................
Symboles sur l'appareil .......................................
Description de l'appareil ......................................
Montage ..............................................................
Montage du tuyau de rallonge.............................
manuel ................................................................
Après l'utilisation .................................................
Stockage .............................................................
Entretien et maintenance ....................................
Dépannage en cas de défaut ..............................
Garantie ..............................................................
Remarques générales
Veuillez lire ce manuel d'instructions ori-
ginal avant la première utilisation de
votre appareil et agissez conformément.
Conservez le manuel d'instructions original pour une
utilisation ultérieure ou pour le propriétaire suivant.
Illustrations et descriptions dans ce
manuel d'utilisation
Les illustrations et descriptions dans ce manuel d'utili-
sation peuvent différer de l'étendue de la livraison et de
la configuration de votre T-Racer.
Remarque
Sous réserve de modifications techniques.
Utilisation conforme
Le T-Racer peut être utilisé avec tous les nettoyeurs
haute pression Kärcher Home & Garden de classe K2 /
K3.
sur les appareils jusqu'à l'année de construction 1991,
un adaptateur est requis (voir « Accessoires et pièces
de rechange »).
Le T-Racer est idéal pour le nettoyage de surfaces de
sols et de murs de différentes surfaces telles que les
carreaux, la pierre, le béton, le plastique et le bois.
Utilisez le T-Racer uniquement pour votre ménage.
