Every time the Setup switch is pressed, the program function is as like :
1) Battery type :
LEDs flashes once for Li-Po , LEDs flashes twice for NiCd/MH.
2) Motor rotation direction selecting:
LEDs flashes once for Forward direction, LEDs flashes twice for Reverse direction.
3) Heli Model : LEDs flashes once for Governor Off, LEDs flashes twice for Governor On.
Boat & Car Model : LEDs flashes once for One Way, LEDs flashes twice for Two Way.
4) Select Model :
LEDs flashes once for Air, LEDs flashes twice for Heli
LEDs flashes three times for Boat, LEDs flashes four times for Car
After you finish your wanted setting, press the Setup switch for over 2 seconds then the ESC should store the setting values, the
motor should beep Mi, Re,Do sound the the Red LED should flash which means you can not select other program function.
At this stage, if you want to change another program parameter, repeat the procedure above, or if all settings are complicated,
turn off the speed controller.
The basic operation on the ESC when the power is on.
Stick safety location ( throttle minimum )
Note) after ONLY hearing Do and Re~~~~ or Do,Re~~~Do,Re,Mi sound, you can set Stick position or Programmable mode
setting.
• LED status during operation.
Full Throttle
Neutral
Full Reverse or Full Brake :
Error
• additional comments on the Error
No Signal : Red LED should flash for 5 seconds then OFF. Waiting for the signal.
High Temperature, Low Battery : Green LED should be ON at the neutral position, and if the stick moves, the Red LED should
flash.
Graupner GmbH & Co. KG wishes you many safe flights and happy landings.
EG declaration of conformity
for the products
PROGRAMMER for BRUSHLESS CONTROL Order-No. 7230
BRUSHLES CONTROL 8 Order.-No. 7231
- BRUSHLES CONTROL 70 Order.-No. 7237
We confirm that the electromagnetic compatibility directives (2004/108/CE) are met.
Harmonized standards applied:
EN 61000-6-1
EN 61000-6-3
Graupner GmbH & Co. KG
Henriettenstr. 94-96
73230 Kirchheim/Teck
Managing Director Hans Graupner
73230 Kirchheim/Teck, 05.08.08
Environmental Protection Notes
When this product comes to the end of its useful life, you must not dispose of it in the ordinary domestic waste.
The correct method of disposal is to take it to your local collection point for recycling electrical and electronic
equipment. The symbol shown here, which may be found on the product itself, in the operating instructions or on
the packaging, indicates that this is the case.
Individual markings indicate which materials can be recycled and re-used. You can make an important
contribution to the protection of our common environment by re-using the product, recycling the basic materials o
recycling redu
ndant equipment in other ways.
Remove batteries from your device and dispose of them at your local collection point for batteries.
If you don't know the location of your nearest disposal centre, please enquire at your local council office.
Specifications:
Do,Re sound.
:
Red LED on
:
Green LED on
Both LED on
:
Red LED flashes
Signature
