Carton Inventory

Your garage door opener is packaged in one carton which
contains the motor unit and all parts illustrated below.
Accessories will depend on the model purchased. If
anything is missing, carefully check the packing material.
Multi-Function
Door Control Panel
Door Control Button
Model LC250
Model PD210CDV
Model HD200CD
Trolley
2-Conductor Bell Wire
White & White/Red
Rail
Front (header)
Section
Safety Reversing
Sensor Bracket (2)
Model PD210CD (1)
Model PD210CDV (1)
Model PD212CD (2)
Model LC250 (1)
Model HD200CD (1)
®
SECURITY✚
Single-Button Remote Control
Motor Unit with a Light Lens
(varies depending upon
model purchased)
Chain and Cable in
Dispensing Carton
"U" Bracket
The Protector System
(2) Safety Reversing Sensors
(1 Sending Eye and 1 Receiving Eye)
with 2-Conductor White & White/Black
Bell Wire attached
Hardware for assembly and installation is shown on the
next page. Save the carton and packing material until
installation and adjustment is complete.
Model PD612CD (2)
Model LC500 (2)
SECURITY✚ ®
3-Button Remote Control
Rail
Center/Back
Sections
Hanging Brackets
®
6
Idler Pulley
Door Bracket
Header Bracket
Curved Door
Straight Door
Arm Section
Arm Section
Safety Labels
and
Literature
Chain Spreader
