5.

Description of functions

max. 6 bar
PLC / DCR / SCR
Connect hand tool PLC with quick-release coupling to the
compressed air network. Max. air pressure: 6 bar. The air
consumption is 600 l/min.
Important:
This tool may be operated only in combination with a compressed
air maintenance unit, consisting of a pressure reducer, water
separator and oiler (see connection diagram).
This unit cleans the compressed air, removes condensation water
and constantly supplies the motor with the required quantity of oil.
The oiler is set on the top with a screwdriver so that one drop of oil
falls in the inspection glass every time a strap is crimped. To
reduce the amount of oil, turn clockwise; to increase the amount of
oil, turn counter-clockwise.
The maximum hose length between the maintenance unit and the
strapping tool: 10 m.
Never operate the tool when there is no oil in the oiler, since
this will result in the immediate destruction of the air motor!
In this case, all warranties shall be excluded.
The air motor must be operated with filtered and oiled compressed
air at all times during operation. Approximately 3-5 drops of oil are
3
needed for each 1m
Preferably, non-gelled mineral oil should be used for lubrication.
The oil must be of low viscosity, resin-free and acid-free. A
0
viscosity of 2-4 E at 50
other temperature ranges, see viscosity table). Motor temperatures
between -30 and +100
At ambient temperatures below +5
of freezing. In this case we recommend using dried air or suitable
anti-freeze lubricants (e.g. "Killfrost" Anti-Ice).
Always wear a breathing mask when using antifreeze
compounds.
The following oils can be used:
Esso D 32
D 100
CL 322
DEA Aries 32
Aries 100
Shell
Tonna Oel R32
Tonna Oel R100
Mobil Almo 525
Almo 527
Almo 528
H456 EU 44/09
of air, or 01.12 – 0.2g/m
0
C (12-30c St) has proven to work well (for
0
C are permitted.
0
C, however, there is a danger
-10 to +30
+25 to +55
+45 to +75
-25 to +20
-10 to +30
+25 to +55
-20 to +20
above +15
3
.
0
C
0
C
0
C
0
C
0
0 to +50 C
0
C
0
C
0
C
0
0 to +30 C
0
C
