Step 3. Connect the fence
a) Connect the energizer's red output ( ) terminal to the fence using
Underground Cable (G627). Remove 5cm (2") of plas c coa ng from one end
of the cable. Unscrew the red (FENCE) terminal and insert the wire through the
terminal slot. Screw the terminal closed, ensuring the wire is fi rmly clamped.
b) A ach the other end of the cable to the fence using a Joint Clamp (G603).
For instruc ons on fence installa on see the Gallagher Electric Fence Guide or go to
www.gallagher.com
Step 4. Turn the Energizer On
a) Connect the power cable of the Energizer to either:
i)
Black
b) Check that the Power On LED on the front of the energizer is green.
c) Re-a ach the orange terminal cover.
Leadset
Red
12 V
12 volt ba ery via the
leadset (G58210)
OR ii)
110/230 VAC mains power
DC adapter (G40132)
