(Must keep all material for returns or refunds)
Range Hood Box
{A} KOBE Range Hood – 1
{B} Warranty Registration Card – 1
{C} Quick Reference Guide
{D} Baffle Filters – 2 (30" hood)
– 3 (36" hood)
{E} 6" Round Plastic Collar – 1
{F} Stainless Steel Spacer – 2 (30" hood only)
{G} Wire Cap x 3
{H} Screws Package
{A}
{E}
Optional Accessories: TVC20 (Top Vent Cover)
(Sold Separately)
{I} 3-1/4" x 10" Exhaust – 1
{J} Top Vent Cover – 1
{I}
FOR MORE INFORMATION, PLEASE VISIT OUR W EBSITE
CONTACT KOBE RANGE HOODS AT (626) 775-8880.
{B}
{F}
Spacer attached
to hood (30" only)
{J}
{C}
{G}
Wire caps (3)
www.koberangehoods.com
5
{D}
Knobs attached
to baffle filter
{H}
M4 x 3/4" (4)
M4 x 1-1/4" (4)
OR
