EN
latch movement. Fasten the latch side assembly firmly. Glue the
tube bushes to the panel. The bushes can be bolted if necessary.
Fig. 95 If the door is manually operated, you can install a cord for easier
door closing.
Fig. 100 Install the door lift handle.
Fig. 105 If a drive unit is installed, lock the latch open.
Fig. 110 Power-operated doors can have the drive link trimmed short to
achieve the full clearance (Hj = Ho - 60).
Fig. 115 Before commissioning the door, lubricate the hinges, running roll-
ers and springs with e.g. Wurth HWS-100 semiliquid grease.
[A000007] 7. ADDITIONAL REQUIREMENTS
After the installation is completed, it must be checked that the door is fitted with
CE data plate according to the standard. If this plate is missing, fit the door with
such a data plate. After verifying the correct operation of the door, the Assembly
and Operating Instruction and door report book, if required, should be handed
over to the Owner.
[A000015] Activities, which may be performed by the Owner after careful
reading of the Assembly and Operating Instruction supplied with the door.
When the door is installed, the protective foil should
be immediately removed from the door leaf. Failure
to do so will result in a strong adherence of the foil to
the door sheet metal under the influence of tempera-
ture and sun rays. This will make it impossible to re-
move the foil and may lead to coating deterioration.
[A000008] 8. ENVIRONMENTAL PROTECTION
Packaging
Elements of packaging (cardboard, plastics, etc.) are classified as waste suitable
for recycling. Follow local legislation for specific material before throwing it away.
Scrapping
The product consists of many different materials. Most of the materials used are
suitable for recycling. Sort it before disposal, and then deliver to refuse collec-
tion and disposal area for recycling.
Follow local legislation for specific material before
scrapping.
[A000009] Remember! Recycling of packaging materi-
als saves natural resources and reduces the amount
of wastes.
[A000118] This device is marked in accordance with European Directive
2012/19/EU on waste electrical and electronic equipment and Directive
2006/66/EC of the European Parliament and of the Council on batteries and
accumulators and waste batteries and accumulators and repealing Directive
91/157/EEC. This marking informs that the device and batteries cannot be dis-
posed of with other household waste after they have been used. The user is
obliged to submit (hand over) devices and batteries to entities dealing with col-
lection of waste batteries and electrical and electronic equipment. The collecting
entities, including local collection points, shops and municipal units, create an
appropriate system enabling the submission of such equipment and batteries.
Proper handling of waste batteries, electrical and electronic equipment contrib-
utes to avoiding harmful consequences for human health and the environment
resulting from the presence of hazardous components and improper storage
and treatment of such equipment and batteries.
[C000033] 9. DOOR DISASSEMBLY
• Open the door and secure the leaf against falling down.
• Release the tension of door springs.
• Carefully close the leaf.
• Perform the assembly procedure in the reverse order.
[A000029] 10. OPERATING AND MAINTENANCE INSTRUCTION
The Assembly and Operating Instruction is a documentation intended for the
door owner.
Please read carefully this instruction and follow its recommendations. The instruction
includes information ensuring safe usage, operation and maintenance of the door.
[A000010] 11. IMPORTANT INFORMATION AND NOTES
• Please carefully keep this instruction.
• All operating activities must be performed according to the door
Assembly and Operating Instruction.
• Occupational health and safety regulations and recommendations
included in the Assembly and Operating Instruction must be ob-
served during all works related to the door inspections and repairs.
• It is prohibited to change any door components or parts.
4
Assembly and Operating Instructions – Sectional garage door UniPro SNP
[B000006] 12. INFORMATION REGARDING FORBIDDEN DOOR
USAGE
• It is forbidden to open the door if the guides are not mounted.
• It is forbidden to obstruct the door movement area. When operat-
ing the door, make sure there are no people, especially children,
or objects within the door movement area.
• It is forbidden for people to stay, or leave cars or other objects in
a clearance of the opened door.
• It is prohibited to stay, walk, run or drive under the moving door.
• It is prohibited to use the door leaf to lift objects or people.
• Do not allow children to play with equipment. Transmitters for
door operation must be kept away from children. Transmitters
should be kept in dry, moisture-free places.
• It is forbidden to modify or remove any door components! This
may cause damage to parts ensuring the door safe usage.
• [C000260] It is forbidden to install any additional infill or thermal
insulation in the door leaf without the manufacturer's written con-
sent. Springs are precisely adjusted to the door leaf weight, and
all additionally mounted elements may cause its overload and
incorrect door operation.
• [B000013] When the door is installed, the protective foil should
be immediately removed from the door leaf. Failure to do so will
result in a strong adherence of the foil to the door sheet metal un-
der the influence of sun rays. This will make it impossible to remove
the foil and may lead to paint coating deterioration.
• Doors with electric drive must be opened according to drive As-
sembly and Operating Instruction.
• [B000008] The door should be protected against harmful agents
(including corrosive agents, like acids, alkali, salts), which may
damage the paint coating and metal. The door should also be
protected against plaster, paints and solvents which may cause
stains, during finishing or repairing the room.
[C000011] 13. DOOR OPERATING INSTRUCTION
• It is prohibited to obstruct the door movement area.
The door opens vertically upwards. Therefore, no obstacles may
be located in the way of door opening or closing. It is necessary
to ensure that during door movement no persons, especially chil-
dren, or objects are on its way.
Caution! Risk of accident.
• [A000053] It is prohibited to keep using the defective door. It is
particularly forbidden to operate the door, if there is any visible
damage of counterbalancing springs, mounting elements or any
other parts responsible for safe door operation.
• [A000062] Any self-retained repairs of the door are prohibited.
• [B000103] IMPORTANT! Damage due to temperature
difference.
Difference between external (ambient) temperature and internal
(premises) temperature may lead to deformation of the door ele-
ments (bimetallic effect). In this case door operation may result in
its damage.
• [B000007] It is prohibited to keep using the door, if any faults in
its operation, or damage of its components are found. In this case,
immediately put the door out of service, and contact the author-
ized service centre.
[C000012] Check the proper mounting of the door according to As-
sembly and Operating Instruction before its first opening.
The door is mounted properly when its leaf/curtain moves smoothly and its op-
eration is easy.
[B000104] Manually-operated garage doors should be opened and closed
smoothly, without sharp jerks that negatively influence its durability and safe op-
eration.
[C000399] Opening - the door should be operated manually, using the rel-
evant outside or inside handles/ pulls. Improper operation of the door may
cause accident.
Closing - the door should be closed manually by pushing it vigorously using the
handle. As a result, the door self-locking bolts will latch on proper door frame
elements.
Door bolting (lock) - as standard the door is equipped with a lock, which
may be bolted by turning the key counter clockwise 360° (if the door does not
feature a drive unit).
Door unbolting (lock) - use the key or blocking bolt:
• from outside - turn the key 360° clockwise,
• from inside - move upwards the blocking bolt, located next to the lock insert,
and simultaneously turn the handle to the right.
