Rear panel

See the page indicated in parentheses ( ).
Q0 o
q
q
PRE OUT connectors ··························································· (5, 26)
w
Speaker terminals ······························································· (5, 26)
e
DOCK CONTROL jack ······························································ (16)
r
S-VIDEO connector ································································· (16)
t
VIDEO connectors ····························································· (13, 14)
40
i
w e r t
y
Power cord ················································································· (5)
u
Digital audio connectors ··················································· (13, 14)
i
HDMI connectors ····································································· (12)
o
Analog audio connectors ·················································· (14, 16)
Q0
FM/AM antenna terminals ····················································· (16)
u y
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
