Jøtul FS 91 Manuel D'installation page 42

Fig. 1
Product: Jøtul FS 91 / Jøtul FS 92
Hole in wall for external air
Ø 100 mm
525
X
Min. measurements floor plate.
X,Y = according to national standards and regulations.
Jøtul FS 91 / Jøtul FS 92
Hole in floor for external air
Ø 100 mm
Min. distance to combustible wall :
612
350
* 50 mm using semi-insulated chimney/covered flue pipe
down towards the product.
344
100 *
Combustible wall
900134-P00
