Installation principle
Figure :
Service outlet
1
Joint seal, e .g . silicone
2
Floor covering
3
Screed (or system floor)
4
Concrete floor
5
Mounting the service outlet
O pen the hinged cover, e .g . with a slotted
screwdriver .
R emove the mounting support by slackening
the fastening screws and keep it in a safe
place .
D raw the drill holes on the concrete floor and
drill them .
I f necessary, lever out the premarked pipe
entries, e .g . with a slotted screwdriver .
M ount the service outlet on the concrete
floor with suitable fastening materials (e .g .
anchors and bolts) .
