Assembly - Kemper KHS CoolFlow Mode D'emploi

4

Assembly

1
Note!
Observe interference
dimensions!
113 mm
2
Note!
Observe the flow direction!
Install in a straight pipe
section!
70 mm
3
© www.kemper-olpe.de – 09.2021 / K410061500001-00 – 23 /72
113 mm 70 mm
Warning!
The servo drive must be in
the regulating position (open)
during removal or installation
(see P. 26). Mount the servo
drive only on installed
regulating valve.
Warning!
The servo drive may only be
operated when installed on
the regulating valve!
