Assemble & Detach Front Wheel; Assemble & Detach Rear Wheel; Assemble & Detach Armbar; Assemble Canopy - Joie Mytrax Manuel D'utilisateur

Assemble & Detach Front Wheel
see images
-
3 4
Assemble & Detach Rear Wheel
see images
-
5 8
! Operating adapters for turning Dunlop valve to Shrader valve is shown as
- 2
7
if not use them.
! CHECK the tire pressure before using the stroller. DO NOT INFLATE above the maximum recommended
inflation pressure that is written on the side of the tire.
! Over-inflation may cause wheel and/or tire to blowout and could result in serious injury.
Assemble & Detach Armbar
see images
-
9 10

Assemble Canopy

see images
-
11 12
Assemble & Detach Cupholder
see images
-
13 14
The completely assembled stroller is shown as
15

Stroller Operation

Adjust Backrest

see images
-
16 17
There are 4 recline angles for the backrest.
Recline Backrest
To recline the backrest, squeeze the recline handle on the back of the seat, pull down on the backrest.
Raise Backrest
17
To raise the backrest, push up.
! Make sure the recline is set properly for use.

Use Buckle

see images
18 - 19
Release Buckle
18
Press the center button to release the buckle.
15
. Store the adapters shown as
7
8
16
Lock Buckle
Match the waist belt buckle with the shoulder buckle
A "click" sound means the buckle is locked completely.
! To avoid serious injury from falling or sliding out, always secure your child with harness.
! Make sure your child is snugly secured. The space between the child and the shoulder harness is about the
thickness of one hand.
! Do not cross the shoulder belts. This will cause pressure on a child's neck.
Use Shoulder & Waist Harnesses
see images
20 - 23
! In order to protect your child from falling out, after your child is placed into the seat, check whether the
shoulder and waist harnesses are at proper height and length.
- 1
20 Shoulder harness anchor A
20 - 2
Shoulder harness anchor B
- 3
20 Slide adjuster
For larger child, use shoulder harness anchor A and the highest shoulder slots. For smaller child, use shoulder
harness anchor B and the lowest shoulder slots.
To adjust the position of the shoulder harness anchor, turn the anchor to be level with the side facing forward.
Thread it through the shoulder harness slot from back to front.
child's shoulder height. 22
Use slide adjuster to change the harness length. 23
23 - 2
Press the button , while pulling the waist harness to proper length.

Adjust Calf Support

see images
24
The calf support has 2 positions.
To raise the calf support, push it upwards. A "click" sound means the calf is locked completely.
To lower calf support, press the adjustment buttons on both sides of the calf support
- 2
support downwards. 24

Use Front Swivel Lock

see images
25
Push up the front swivel locks to maintain the moving direction.
Tip
It is recommended to use swivel locks on uneven surfaces.

Use Brake

see images
-
26 27
To lock wheels, step the brake lever downwards. 26
To release wheels, just lift the brake lever upwards.
Tip Always set the parking brake when stroller is not moving.
- 1 - 2
19 , and click into the center buckle. 19
- 3
19
21
Rethread it through the slot that is closest to
- 1
23 - 3
- 1
24 , and rotate the calf
25
27
