Mounting instructions information
The mounting instructions come as part of the Duravit
product and must be read carefully prior to installation.
Target readership and qualifications
The toilet frame may only be installed by a qualified
plumber. The electrical installation should only be carried
out by qualified electricians.
Explanation of the symbols
Link to the mounting instructions in this section
Link to other instructions
Cold water
Water installation
Inspect to check for leaks and leak-tightness
> Action required

Safety instructions

Risk of fatal electric shock
Contact with electricity can lead to an electric shock.
> Carry out the electrical installation in accordance with
the national, European and international directives and
standards.
Product and/or property damage
A breach of local and country-specific regulations and
standards can cause damage to the product
and/or property damage.
> Observe the local installation regulations and any
country-specific standards at all times.
6
70300107_Toilet frame_Standard
57430_MAL_WC-Element_Standard.indb 6
Prior to the installation
> Check the load-bearing capacity of the wall.
> Please read the pre-installation data sheets.
These are available to download on the Internet at
www.pro.duravit.com.

Mounting instructions

+
8 14 Observing the position of the drain
The height of the drain must be preset at
220/240 mm for the toilet frames. The height of the
toilet frames can be adjusted individually.
> Set the height of the toilet frame based on the
position of the drain according to the technical
drawing of the toilet. There is no marking for the
reference marker with reduced frame heights.
36
SensoWash shower toilet (optional)
®
Duravit recommends carrying out the pre-
installation when subsequently installing the shower
toilet.
37
Installing the water supply for the SensoWash
shower toilet (optional)
The water supply can be provided via a fixed water
installation or subsequently via the empty pipe for
the water installation in the cistern.
Fixed water installation:
> Install the pre-installation set #005072 0000.
Water connection via the cistern:
> Install the connecting kit:
• #WD1011: Connecting kit #100691
• #WD1016/#WD1018: Connecting kit #100730
38 Installing the power supply for the SensoWash
shower toilet (optional)
> Install the power supply line according to the
instructions for the SensoWash
800 mm cable behind the wall for installing the
toilet at a later date.
39
Installing the power supply for the hygienic flush
(optional)
Optionally only for #WD1011.
> Mount the installation set for the hygienic flush.
43 Observing the load-bearing capacity of the wall
> Please read the pre-installation data sheets.
®
®
or lay an
®
