Specifications
Table 3: Warranted electrical characteristics (Cont.)
n Common mode rejection ratio n Common-mode rejection ratio
n Bandwidth (probe only)
Temperature
Humidity
1
See warning that follows.
WARNING. To avoid a burn hazard at high ambient temperatures, do
not touch the probe with bare hands at operating temperatures above
+ 50_ C or at nonoperating temperatures above + 70_ C.
26
45 dB at 1 MHz in ÷ 10
45 dB at 1 MHz in 10
25 dB at 100 MHz in ÷ 10
20 dB at 500 MHz in ÷ 10 20 dB at 500 MHz in ÷ 10
18 dB at 1 GHz in ÷ 10 18 dB at 1 GHz in ÷ 10
60 dB at 1 MHz in ÷ 1
38 dB at 100 MHz in ÷ 1 38 dB at 100 MHz in ÷ 1
35 dB at 500 MHz in ÷ 1 35 dB at 500 MHz in ÷ 1
30 dB at 1 GHz in ÷ 1
P6246: DC to ≥ 400 MHz (-- 3dB)
P6247: DC to ≥ 1 GHz (-- 3dB)
Operating: 0 to + 50_ C
1
0 to + 60_ C
Nonoperating: -- 55 to + 75_ C
Operating: 0--90% RH, tested at
+ 30 to + 50_ C
Nonoperating: 0--90% RH, tested at
+ 30 to + 60_ C
P6246 & P6247 Instructions
(probe head)
