UK
1
WARNING
This pump is (manufactured
in a factory which is quality)
certified to ISO 9001, ISO
14001. Installed and used
correctly, the unit will give
consistent and reliable ser-
vice. This device is not desi-
gned for persons (including
children) with limited physi-
cal, sensory or mental abili-
ties, or those with minimal
experience and knowledge,
unless they are monitored
and are given the neces-
sary instructions for using
the device, with the help of a
person responsible for their
safety.
Monitor children and make
sure they do not play with
the device.
2
DESCRIPTION
This item of equipment is a lift pump
for waste water from a shower or a
washbasin. It starts automatically.
3
INSTALLATION
The equipment must be easily accessible
for inspection and maintenance. The pump
is fitted with fastening systems to prevent
it from turning or moving.
CONNECTING UP THE SIDE INLETS
Use a sleeve D to connect up the side inlet
of the tank (see fig.2).
CONNECTING UP THE SHOWER
TRAY
• Installation alongside the shower tray
(see fig. n° 6A). Connect one end of the
sleeve to the lower inlet on the unit and
the other end to a tube of 40 mm diam ext.
Fix it using the collar. Use pliers to tighten
the collars.
Attention: make sure that the shower
outlet is at least 120 mm above the
floor.
• Installation under the shower tray (see
fig. n° 6b ):
Raise the shower tray by at least 150 mm
to leave room for the unit.
Attention: Install an inspection cover
for the unit, measuring at least L=400
mm x H=150 mm. The system adop-
ted to open the cover must involve
the use of a tool.
CONNECTING UP THE WASTE
OUTLET PIPE (see fig. 1 and 5):
• Insert the elbow A in the rubber outlet
and fix it in place with a collar.
• Connect the check valve B to the other
end of the elbow and fix it in place with
a collar.
• If the check valve is fitted horizontally,
use rigid 22 mm tube to connect the unit
to the valve inlet (see fig. 1)
TECHNICAL ADVICE FOR THE
WASTE SYSTEM
To avoid siphoning, install a vacuum brea-
ker at the high point of the installation.
IF WORK IS REQUIRED
Install a drain-valve at the low point of the
waste outlet riser pipe to enable it to be
drained if work is necessary.
ELECTRICAL CONNECTIONS
Use a battery that is in good condition and
6
FAULT FINDING / REMEDIES
IN ALL CASES, YOU MUST DISCONNECT
THE PUMP FROM THE POWER SUPPLY
SYMPTOMS
• The motor does not activate
• The motor intermittently
activates
• The motor operates normally, but
does not stop or continues to run
for a long time
• The unit stops
• Soiled water comes up into
the shower basin (units with
side inlets)
7
GUARANTEE
2 years guarantee as from its date of purchase subject to correct installation and correct use.
Warning : Do not dispose of solvents, paints (do not wash paint brushes in sink),
caustic, acid or other chemicals into these products.
3
is able to supply the necessary current:
12V=28A / 24V=15A. We recommend
adding a 30A circuit breaker for a 12V
installation and a 20A circuit breaker for
a 24V system.
4
COMMISSIONING THE
UNIT
Once electrical and plumbing connections
have been made, check that all seals, and
connections are watertight.
Check both the discharge pipework from
the unit and the other sanitary appliances
connections.
5 MAINTENANCE
WARNING !!!
If away for a long period, we recommend
that you turn off the water supply to the
WC served by the unit.
CARE OF YOUR UNIT
In order to remove scale and clean the
pump, use a household descalent (like
SANIFLO Cleanser/descalent).
PROBABLE CAUSES
• The electrical power supply • Restore the electrical supply
is not active
• The electrical power supply is • Check the electrical power
defective
• The motor or the control system • Otherwise, ask an approved
is defective
• The connected sanitary devices • Check the installation upstream
are leaking
• The non-return valve is faulty • Clean or replace the non-return
• The length or height of the • Check the installation
installation is over the
specification, or there are too
many bends/elbows
• The pump cover plate is • Otherwise, ask an approved
occluded
• The unit has been running for • Wait for reset, then ask an
too long (thermal cut-out)
• Shower installed too low as • Check the installation
compared with the pump
• Hinged side inlet discs • Clean the hinged discs
clogged up • Otherwise, ask an approved
REMEDIES
supply
repair agent to intervene
valve
repair agent to intervene
approved repair agent to
intervene
repair agent to intervene
