Liste Des Pièces
Item Part #
27 N010-0821
28 N010-0822
29 N570-0073
30 Z570-0033
31 N100-0047
32 N100-0046
33 N655-0158
N655-0158-BK1HT
34 N655-0159
N655-0159-BK1HT
35 Z570-0029
36 N325-0082
37 N485-0023
38 N485-0021
39 N080-0302
40 N305-0087-BK2FL
41 N305-0088-BK2FL
42 N735-0018
43 N720-0067-SS1SG
N720-0067-BK1FL
44 N272-0001
45 N325-0084
46 N160-0037
47 N010-0806-SS1SG
N010-0806-BK1FL
48 Z745-0001
Z745-0001-BK
49 N015-0009
50 N160-0026
51 N450-0043
52 N655-0200
N655-0200-BK1HT
53 N655-0201
N655-0201-BK1HT
54 N390-0003
55 N685-0017
N685-0017-BK
56 N135-0048-BK1HG
N135-0048-BK1HL
57 W450-0027
58 N255-0057
59 N255-0014
60 N640-0003
N415-0437CE-FR AUG 04.20
Description
left drip pan bracket
right drip pan bracket
1/4-20 x 3/8" screw
10-24 x 12mm screw
right burner
left burner
left bottom support handle
left bottom support handle, matte black
right bottom support handle
right bottom support handle, matte black
10-24 x 35mm screw
top/bottom handle
clevis pin
cotter pin
cross light bracket
left cooking grid
right cooking grid
leg pivot washer
foot frame tube
foot frame tube, matte black
scissor cart foot
scissor cart foot handle
CE tank strap bracket
wheel side frame
wheel side frame, matte black
wheel
wheel, black
axle
side shelf folding clip
axle cap
left top handle support
left top handle support, matte black
right top handle support
right top handle support, matte black
handle latch
temperature gauge
temperature gauge, black
lid casting
lid casting, matte black
1/2" brass nut
3/8" - 1/4" union fitting
fitting
regulator strap
PRO285X-BK PRO285X-MK-PHM
x x
x x
x x
x x
x x
x x
x
x
x
x
x x
x x
x x
x x
x x
x x
x x
x x
x
x
x x
x x
x x
x
x
x
x
x x
x x
x x
x
x
x
x
x x
x
x
x
x
x x
x x
x x
x x
