3

INSTALLATION OF BATTERIES

Slide and remove the battery cover (2).
Pull out the battery container (1) using the attached strap.
Slide batteries (or rechargeable batteries) into the battery container. Pay attention to «+» (positive) and «-»
(negative) symbols marked on the walls of the container.
Insert the battery container back into the battery compartment. Make sure the battery container is re-inserted
properly, particularly watching for the orientation of the battery container contacts.
Slide back the battery cover to its original position.
Attention! Do not use batteries of different types or batteries with various charge level because this may
significantly decrease operating time.

EXTERNAL POWER SUPPLY

The unit can operate on an external battery such as Power Bank (5V) or a computer (laptop).
Connect the plug of the USB cable (5) to the unit's USB port (4).
Connect the other plug of the USB cable to a Power bank or a computer.
Upon connection of an external power supply the unit stops operating on batteries.
Operation on external power supply is shown with an icon
More about powering from Power Bank and computer in section 14.
3
5
EXTERNAL VIEW AND CONTROLS
1 Battery container
2 Battery container cover
3 Short range IR Illuminator
Micro USB port
4
5 Micro USB cable
Eyepiece diopter adjustment ring
6
7 Display brightness adjustment wheel
Objective lens
8
6

DESCRIPTION OF CONTROLS

Button Operating mode st
1 short press
ON The unit is off Turns the unit on
The unit is in Video / Photo mode Turns the Wi-Fi on
The unit is in Review mode File deletion prompt
ZOOM Video Digital zoom activation
Review Switch between files – leftwards navigation
Return to the beginning of file under review
Video Start video recording
REC
Photo Image capture
Review Recorded video review
IR Video Switch between IR Illuminator modes
Review Switch between files - rightwards navigation
9 Radiator
10 Long range IR Illuminator
11 Objective lens and IR covers
12 Button REC
13 Button IR
Button ZOOM
14
15 Button ON
LED Indicator
16
nd Long press
2 short press
Turns the Wi-Fi on Turns the display on/off
Turns the Wi-Fi off (hold longer than 1 sec)
Turns the unit off
See description of Review Mode
(hold longer than 3 sec)
Enter the menu
—
Stop video recording Switch to Photo Mode
Image capture Switch to Review Mode
Pause video review Switch to Video Mode
Turns the IR Illuminator off
—
4
