DESCRIPTION OF PARTS

Fig. 2 - Transmitter
1 Pt1 button
2 Setting dip-switches
3 Indicator LED
4 Terminal board for sensitive edge input
Fig. 5 - Receiver
1 Setting dip-switches
2 Indicator LED
3 Pr1 memorisation button
4 TEST input terminal board
5 Power supply and SENSITIVE EDGE signal output terminal
board
6 COSTA 2 (SENSITIVE EDGE 2) setting jumper
7 COSTA 1 (SENSITIVE EDGE 1) setting jumper
8 12/24 V power supply selection jumper
INSTALLING TRANSMITTER
1) Mount the transmitter in the highest point of the gate and near
the sensitive edge (Fig. 1).
2) Connect the sensitive edge to the clamp of the transmitter, with
a cable max 5 meters long and section minimum 1mmq (4 in
Fig. 2).
The sensitive edge must be of the 8.2 kOhm balanced NO
type. If you use a NC sensitive edge you must use the
resistence 8,2 KOhm in series. Run the cables as closely as
possible to the terminal board (Fig. 2).
3) Insert the batteries into the transmitter taking great care with
the polarity and check that the LED (3 in Fig. 2) lights up
momentarily.
