Control buttons and functions
Button
1
2
3
(optional)
4
5
(optional)
6
(optional)
LED A
(optional)
LED B
(optional)
LED C
(optional)
Operation Manual (Version: B)
Function
Main switch /
Emergency stop
Deck up, Extend /
Retract lip
Side switch ON/OFF
Auto Return
Door open/close/ stop Only possible when door is controlled by
Inside traffic lights
Fault/status LED (red) This red LED will light up if a fault has occurred.
status LED (green)
status LED (green)
Description
Turns power to the control box on or off.
The switch can be locked with a padlock in the
off position.
Push for normal operation.
Push briefly to release certain functions.
used for optional inflatable shelter (blower
on/off).
Returns the deck to parked (standby) position.
control box.
Signals if loading and unloading is allowed
(=door open, leveller in truck) or not.
When the fault is corrected the LED will go out.
The green LED indicates that the leveller can
be operated.
The green LED indicates that the door can be
operated.
25 Type XF
