Symbol Meaning
Weight
Switching On
Switching Off
Permitted action
Prohibited action
Accessories/Spare Parts
Intended Use
The garden product is intended for domestic lawnmowing.
Technical Data
Lawnmower
Article number
Rated power input
Blade width
Height of cut
Grassbox, capacity
Weight according to EPTA-
Procedure 01:2014
Protection class
Serial number
The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
Troubleshooting
TOP
Problem Possible Cause
Motor refuses to start Power turned off
Mains socket faulty
Extension cable damaged
Fuse faulty/blown
Grass too long
Motor protector has activated
Machine functions Extension cable damaged
intermittently
Internal wiring of machine damaged
Motor protector has activated
Bosch Power Tools
Noise/Vibration Information
Sound emission values determined according to
EN 60335-2-77.
Typically the A-weighted noise levels of the product are:
Sound pressure level 79 dB(A); sound power level 93 dB(A).
Uncertainty K=2.0 dB.
Wear hearing protection!
Vibration total values a
determined according to EN 60335-2-77:
a <2.5 m/s
h
Mounting and Operation
Action
Delivery Scope
Handle Assembly
Snap together the Grassbox
Grassbox fitting/removing
Rotak 320 ER
Adjusting the Cutting Height
0 600 8A6 0..
Connecting the extension lead
W 1200
Starting
cm 32
Stopping
mm 20 – 60
Working Advice
l 31
Blade Maintenance
Selecting Accessories
kg 8.0
/II
see type plate on
the garden product
(triax vector sum) and uncertainty K
h
2 2
, K=1.5 m/s .
Figure
1
2
3
3
4
5
5
5
5 – 6
7
7
Corrective Action
Turn power on
Use another socket
Inspect cable, replace if damaged
Replace fuse
Increase height of cut and tilt garden product to re-
duce starting load
Allow motor to cool and increase height of cut
Inspect cable, replace if damaged
Contact Service Agent
Allow motor to cool and increase height of cut
F 016 L81 624 | (2.8.16)
English | 13
Page
183
183
184
184
184
184
184
184
184 – 185
185
185
