FLUID HOSE
10
Fluid hose with hose nozzle and black sealing ring. Connect the fluid hose to the canister cover by inserting thehose nozzle into the quick
connector until the locking mechanism engages. Make sure that the connection is tight. To release the fluid hose, press the spring-loaded
release button (no. 11).
11 RELEASE BUTTON
To release the fluid hose from the special cover, press the spring-loaded release button (no. 11) of the quick connector.
VENTILATION VALVE
12
Ventilation valve with corresponding hose.
INTAKE HOSE
13
Intake hose with sinter filter.
Before replacing the canister or refilling fog fluid, disconnect the fog machine from the power supply (remove the power plug).
The special canister cover with ventilation valve and intake hose, suitable for 5l Cameo fog fluid canisters, included in delivery (canister not
included). Place a full Cameo fog fluid canister upright in front of the fog machine and unscrew the canister lid. Now take the included spe-
cial cover and insert the hose of the ventilation valve and the intake hose (no. 12 and 13) into the canister and screw the special cover tight
to the canister. The sinter filter on the intake hose ensures that contaminant particles do not get into the system and that the hose end is
always at the lowest point of the canister. Now set the canister into the canister compartment and connect the fluid hose of the fog machine
on the special cover (see no. 10). To remove a fluid canister, please first loosen the fluid hose from the special cover.

OPERATION

NOTES
• After connecting to the power supply, "Welcome to Cameo", the model designation, and the software version will display one after the
other. At the same time, the vaporizer will heat up (approx. 7 minutes), during which "Heating ..." will be shown on the display; system
settings can be applied as needed during this time.
• After the heating phase is complete, "Ready!" will display briefly and then the operating mode previously selected will activate.
• When the heat-up phase is complete, fog will only release when the main screen shows one of the available operating modes (DMX,
Stand Alone, Timer, Slave mode); the fog discharge halts automatically as soon as one of the menu options is chosen from the options menu
or submenu in order to prevent injury from the discharged fog.
• Do not operate the fog machine without fog fluid! When the canister runs out during use, the fluid pump is switched off automatically for
protection purposes, "Low Liquid Protection" is shown on the display, and the canister light simultaneously starts to flash. Disconnect the
fog machine from the power supply before changing the canister or filling it with fog fluid. Then, use the "Instant Fog" function (maximum
fog discharge) in order to completely fill the fluid hose with fog fluid again, in order to prevent the automatic pump switch-off from reactivating.
• In order to remove fluid residue in the vaporizer system of your fog machine and thus ensure a long service life, clean the vaporizer sys-
tem regularly (approx. every 60 operating hours). To do so, use the special Cameo cleaning fluid for fog machines and follow the instruction
on the bottle label.
SETTING THE DMX START ADDRESS (DMX Address)
You can access the options menu by pressing MODE. Using the UP and DOWN control keys, now select the "DMX Address" menu option and
confirm via ENTER. Use the UP and DOWN keys to set the desired DMX start address and confirm this entry via ENTER. The main screen
now displays the operating mode and DMX start address and automatically activates the DMX operating mode.
ENTER
DMX address
UP/DOWN
DMX address
ENTER
001 - 5XX
Main display
DMX-Mode
DMX-Address: xxx
