Bosch PSB 14,4 LI-2 Notice Originale page 10

10 | English
Additional Safety and Working In-
structions
 Dusts from materials such as lead-containing coatings,
some wood types, minerals and metal can be harmful to
one's health and cause allergic reactions, lead to res-
piratory infections and/or cancer. Materials containing
asbestos may only be worked by specialists.
– Provide for good ventilation of the working place.
– It is recommended to wear a P2 filter-class respirator.
Observe the relevant regulations in your country for the mate-
rials to be worked.
 Prevent dust accumulation at the workplace. Dusts can
easily ignite.
 To save energy, only switch the power tool on when using
it.
 The battery is supplied partially charged. To ensure full
battery capacity, completely charge the battery in the
battery charger before using for the first time.
 Read the operating instructions of the battery charger.
 Apply the power tool to the screw only when it is
switched off. Rotating tool inserts can slip off.
 Adjust the gear switch only when the machine is at a
complete stop.
 Always push the gear selector and turn the operating
mode selector switch through to the stop. Otherwise,
the machine can become damaged.
 When the On/Off switch is pressed halfway or com-
pletely, the battery charge-control indicator indicates
the charge condition of the battery for several sec-
onds. It consists of 3 green LEDs.
LED
Continuous lighting 3 x green
Continuous lighting 2 x green
Continuous lighting 1 x green
Slow flashing 1 x green
 The 3 LEDs of the battery charge-control indicator
flash rapidly when the battery temperature is not with-
in the operating temperature range of –30 to +65 °C,
and/or when the overload protection has responded.
Symbols
The following symbols are important for reading and under-
standing the operating instructions. Please take note of the
symbols and their meaning. The correct interpretation of the
symbols will help you to use the machine in a better and safer
manner.
1 609 92A 13X | (11.2.15)
Symbol
Capacity
≥ 75 %
50 – 75 %
26 – 50 %
≤ 25 %
U
n
S
n 1
0
n 2
0
M
Meaning
PSB 14,4 LI-2/PSB 1440 LI-2/
PSB 18 LI-2/PSB 18-00 LI-10
Combination Cordless Drill
Grey-marked area: Handle (insulated
gripping surface)
Article number
Read all safety warnings and all instruc-
tions
Before any work on the machine itself,
remove the battery
Always wear ear protection.
Movement direction
Reaction direction
Drilling and screwdriving
Impact drilling
Low speed
High speed
Switching On
Switching Off
Right/left rotation
Rated voltage
Impact rate
No-load speed (1. gear)
No-load speed (2. gear)
Maximum torque according to ISO 5393
Brickwork
Bosch Power Tools
