HEIDENHAIN GAGE-CHEK 2000 Guide D'installation page 21

4 Mounting
4.1 Overview
This chapter describes the mounting of the product. It
contains instructions about how to correctly mount the
product on stands or holders.
The following steps must be performed only
by qualified personnel.
Further information:
Page 20
4.2 Assembly of the product
General mounting information
The mount for the mounting variants is provided on the
rear panel. The mounting hole pattern corresponds to a
grid of 50 mm x 50 mm.
Further information: "H", Page 179
The material for attachment of the mounting variants on
the device is included in delivery.
You will also need the following:
Torx T20 screwdriver
Torx T25 screwdriver
Allen key, size 2.5 (Duo-Pos stand)
Material for mounting on supporting surface
The unit must be mounted to a stand or a
holder to ensure the correct and intended use
of the product.
HEIDENHAIN | GAGE-CHEK 2000 | Installationsanleitung | 12/2018
"Personnel qualification",
Mounting on Duo-Pos stand
You can fasten the Duo-Pos stand to the product at a 20°
or 45° angle.
If you screw the Duo-Pos stand into the
product at a 45° angle, you must attach the
product at the upper end of the mounting
slots. Use a power cable cable with an angled
connector.
Use the provided M4 x 8 ISO 7380 hexagon socket
screws to fasten the stand to the lower threaded holes
on the rear panel
Comply with the permissible tightening torque
of 2.6 Nm
Using the mounting slots (width = 4.5 mm), screw the
stand to a supporting surface
or
Set up the device freely at the desired location
Route the cable from behind through the two supports
of the stand and then through the lateral openings to
the connections
"C", Page 4
Further information:
Dimensions of the Duo-Pos stand
Further information: "J", Page 180
4.2.1 Mounting on Multi-Pos stand
Use the provided M4 x 8 ISO 14581 countersunk head
screws (black) to fasten the stand to the threaded
holes on the rear panel
Comply with the permissible tightening torque
of 2.6 Nm
Using two M5 screws, you can also optionally screw
the stand to a supporting surface from the bottom
Adjust the desired angle of inclination
To fix the stand: Tighten the T25 screw
Comply with the tightening torque for
screw T25
Recommended tightening torque:
5.0 Nm
Maximum permissible tightening
torque: 15.0 Nm
Route the cable from behind through the two supports
of the stand and then through the lateral openings to
the connections
Further information: "D", Page 4
Dimensions of the Multi-Pos stand
Further information: "K", Page 180
23
